Hercules II 600 Commercial Vertical Lift

spacer

Prices are in U.S. Dollars

spacer

AmeriGlide's Hercules II 600 Commercial Vertical Lift, with its incredible 600 pound lifting capacity, can eliminate the barriers stairs create for virtually anyone. Need a vertical lift for outside your business? Need a vertical lift for inside your office? The Hercules II 600 Commercial Vertical Lift is the easy solution.

The Hercules II 600 Commercial Vertical Lift is built strong and offers many features - features that would cost extra on competitors' lifts - free of charge. These include: weather resistant controls, top and bottom limit switches, a 42" high guard panel, and a fixed ramp. The lift's platform is a solid style platform with safety plate and comes standard with a solid handrail and paddle controls. With all these features the Hercules II 600 Commercial Vertical Lift is the safe, strong, and economical solution to the obstacles found in public buildings, private businesses, places of worship, schools, and more.



  • 600 lb. weight capacity
  • Solid handrail
  • Solid platform
  • Platform safety plate
  • Constant pressure controls
  • Switches and controls are weather resistant
  • Top limit switch allows you to set the stop of the vertical lift at any height (up to the maximum lift height)
  • Bottom limit switch also included
  • 36" x 54" non-skid platform
  • 42" high solid side platform walls
  • Large number of options to meet commercial regulations
  • Some assembly required
  • ASME A18.1, Section 2 - "Vertical Platform Lifts" compliant when properly configured
  • CSA B44.1 / ASME 17.5 - "Elevator and Escalator Electrical Equipment" compliant when properly configured

Contact us and one of our vertical lift experts will answer all of your questions about our Hercules II Commercial Vertical Lift and any accessories you may need.

ETL Listed
spacer

Options Available for the Hercules II 600 Commercial Vertical Lift

  • Lifting Height
    • 53" Max Lift Height  $0.00
    • 77" Max Lift Height  $685.00
    • 101" Max Lift Height  $1,909.00
  • Crating & Assembly
    • No Crating - Some assembly is required.  $0.00
    • 36" x 54" Platform  $0.00
    • 53" Unit Shipped Crated & Fully Assembled  $460.99
    • 36" x 60" or 42" x 54" Platform - Requires Extra Large Crate  $0.00
    • 53" Unit Shipped Crated & Fully Assembled  $690.99
  • Tower Orientation
    • Tower On The Left  $0.00
    • Tower On The Right  $0.00
  • Power Source
    • AC Powered  $0.00
    • DC Battery Powered  $1,020.99
  • Electronics
    • A commercial electronics control board allows operation with doors, gates, multiple call/send controls, and other devices.  $0.00
    • Commercial Electronics Control Board  $0.00
  • Platform Type
    • 36" x 54" Straight Thru (34" Usable Width)  $0.00
    • 36" x 48" Straight Thru (34" Usable Width)  $244.99
    • 36" x 54" 90 Degree (34" Usable Width)  $355.99
  • Platform Access
    • Straight Thru or 90 Degree  $0.00
    • Same Side Entry & Exit - Lift height must be 101"  $368.99
  • Platform Gate
    • Lifts 8' and over that are not in a hoistway require a platform gate or an interlock for a customer provided gate.  $0.00
    • No Platform Gate  $0.00
    • Left Swing 36" Wide Straight Thru Platform Gate with Interlock  $614.99
    • Right Swing 36" Wide Straight Thru Platform Gate with Interlock  $614.99
    • Left Swing 42" Wide Straight Thru Platform Gate with Interlock  $860.99
    • Right Swing 42" Wide Straight Thru Platform Gate with Interlock  $860.99
    • Left Swing 90 Degree Platform Gate with Interlock  $1,290.99
    • Right Swing 90 Degree Platform Gate with Interlock  $1,290.99
  • Platform Controls
    • Paddle Controls with Emergency Stop Button  $0.00
  • Platform Control Options
    • Emergency Stop Alarm  $257.99
    • Emergency Stop Alarm & Lighted Button  $195.99
    • Keylocks for Controls (each)  $47.99
  • Platform Options
    • 42" High Side Walls  $0.00
    • Solid Platform with Safety Pan  $0.00
    • Inside Grab Bar  $0.00
  • Ramp Type
    • Fixed Ramp; standard  $0.00
    • Auto-Folding Ramp (Only for up to 60" of travel)  $134.99
    • No Ramp with Pit Switch Option  $121.99
  • Landing Gate
    • Landing gates below include an interlock and a call/send control built into the gate.  $0.00
    • Left Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)  $811.99
    • Right Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)  $811.99
    • Left Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)  $983.99
    • Right Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)  $983.99
    • Keylocks for Controls (each)  $47.99
    • Landing gates below include an interlock only.  $0.00
    • Left Swing 36" Wide Landing Gate with Interlock Only (each)  $737.99
    • Right Swing 36" Wide Landing Gate with Interlock Only (each)  $737.99
    • Left Swing 42" Wide Landing Gate with Interlock Only (each)  $860.99
    • Right Swing 42" Wide Landing Gate with Interlock Only (each)  $860.99
    • Keylocks for Controls (each)  $47.99
  • Landing Controls
    • Call/Send Control Station (each)  $134.99
    • Keylocks for Controls (each)  $47.99
    • Wireless Call/Send Control Stations (pair)  $454.99
    • Pit Switch  $121.99
  • Hoistway Doors
    • 36" Fire-Rated Door with EMI - Left  $1,845.99
    • 36" Fire-Rated Door with EMI - Right  $1,845.99
    • 36" Fire-Rated Door with Electric Strike - Left  $2,152.99
    • 36" Fire-Rated Door with Electric Strike - Right  $2,152.99
    • 42" Fire-Rated Door with EMI-Left  $2,275.99
    • 42" Fire-Rated Door with EMI-Right  $2,275.99
    • 42" Fire-Rated Door with Electric Strike-Left  $2,583.99
    • 42" Fire-Rated Door with Electric Strike-Right  $2,583.99
  • Interlocks
    • Surface mount EMI interlocks below are for a customer provided door or gate.  $0.00
    • Left Swing Top Landing Door/Gate EMI Interlock (each)  $284.99
    • Right Swing Top Landing Door/Gate EMI Interlock (each)  $284.99
    • Flush mount electric strike interlocks below are for a customer provided door or gate.  $0.00
    • Top Landing Electric Strike Interlock - Metal Frame (each)  $601.99
    • Bottom Landing Electric Strike Interlock - Metal Frame (each)  $601.99
    • Top Landing Electric Strike Interlock - Wood Frame (each)  $601.99
    • Bottom Landing Electric Strike Interlock - Wood Frame (each)  $601.99
    • Other Interlock Options  $0.00
    • Wiring For Interlock (per landing)  $153.99
    • Keyed Dead Latch for Flush Mount Electric Strike Interlock (each)  $121.99
  • Optional Equipment
    • Fascia Panel (per foot)  $72.99
    • Phone Jack  $121.99
    • Emergency Light  $134.99
    • Tower Braces  $153.99
    • Auto Opener for Top Landing or Platform Gate  $1,721.99
    • Auto Opener for Full Door  $2,449.99
    • Outdoor Package (Price is per foot)  $285.72
  • Photo Cells (Required in Michigan)
    • Photo Eyes Minimum of one per landing   $1,085.00
Customer Reviews
3 reviews

0

2

1

0

0
Certified Customer
Vertical Lift
Jun 9, 2011 11:47 AM
A Little About Myself
Pros
Cons
One little mix-up from factory, but sales rep was quick to remedy the situation.
Needs to have better labeled electrical connections from and to locations on the unit itself. Better color photos would also aid in the routing of the wiring.
1 of 1 person found this review helpful
Did you find this review helpful? Yes / No

Certified Customer
Waiting to see the results.
May 27, 2010 3:50 AM
A Little About Myself
Installer
Pros
Safe, Sturdy
Cons
Instructions not clear
The interlock and wiring needs better instructions. We spent more time than necessary and needed multiple calls to tech support for items which could have been handled in the manual.
5 of 6 people found this review helpful
Did you find this review helpful? Yes / No

Certified Customer
Works well.
Nov 23, 2009 11:50 AM
A Little About Myself
Disabled
Pros
Sturdy
Cons
Short warranty
Fits well inside my garage. Not sure how well it would stand up in an outside environment. Easy to install. Even my wife uses it to bring in heavy items.
15 of 17 people found this review helpful
Did you find this review helpful? Yes / No
